FTKY50

3 Star Standard Series

  • Technology :

    Inverter

  • Star Rating :

  • Capacity kW :

    5.0

  • Compressor Warranty :

    10 Yrs

  • PCB Warranty :

    5 Yrs

Get the best and quick air conditioning experience with the Power Chill Operation of FTKY50 series. Designed for your comfort, the series comes with 3 Stage Air Filtration that removes the unnecessary particles, keeping your space’s atmosphere safe.

Salient Features

10 Years Warranty on Compressor

Enjoy long term assurance with 10 Years of peaceful cooling at your house. Daikin provides you tension-free comfort for a decade with a warranty on your air conditioning system's compressor.

5 Years Warranty On PCB

Want additional peace of mind? With Daikin's 5 year warranty on PCB, make your experience more peaceful alongside extra assurance on the maintenance cost and enjoy smooth cooling of your AC in your home.

Coanda Airflow

Make way for effective air circulation and efficient temperature distribution with Daikin’s Coanda airflow, designed to give the best air-conditioning experience. This function ensures cooling even in corners of the room by streaming cool air upwards along the ceiling, avoiding furniture or obstructions.

DNNS Self Heal

Every Daikin Room AC’s Indoor Unit (U-bend side) is coated with advanced anti-corrosive coating active agent DNNS (Di-Nonyl Nephthalene Sulfonic Acid). The coating has Self Healing properties that activates upon chipping, scratches due to environmental or chemical pollution.

Hepta Sense

Daikin Swing Inverter ACs has 7 Sensors located on IDU and ODU. Each of these sensors has role to play in the working of Air conditioner that improves overall performance, provide comfort to users and help to increase durability and life of the AC.

Patented Swing Compressor

Daikin Air conditioners come with a Patented Swing Compressor which decreases friction and vibration. This helps in a smooth rotation of the swing compressor which provides a quiet and efficient operation.

Power Chill Operation

Cool down your home at a fast rate. Daikin's Power Chill operation cools down 20% faster as compared to the normal mode. It ensures your room temperature drops rapidly for immediate relief from the hot temperature outside.

Power-Airflow Dual Flaps

The Power-Airflow Dual Flaps along with the Crossflow Evaporator fans ensure even distribution of cool air in both small and large spaces, making sure you are comfortable at all times.

Stabilizer Inside

No need to worry about voltage fluctuation. Daikin's Stabilizer Inside operation regulates voltage across a wide range of fluctuation (130V~285V) and helps ensuring smooth operations during voltage fluctuations.

Explore All Features

Specification

Model nameIndoor unit (IDU)FTKY50UV16V3/V3A/V39/U39
Outdoor unit (ODU)RKY50UV16V3/V3A/V39/U39
Star Rating* 3 Star
Rated Power SupplyPhase/Frequency/Voltage1φ/50Hz/230V
Power Supply Intake Outdoor unit
Rated Cooling Capacity Full/Half (min.～max.)kW5.0/2.5 (1.9~5.2)
Btu/h17100/8550 (6480~17740)
Cooling Capacity @ 43 Deg ℃%100%
Rated Power Consumption Full/Half (min.-max.)W1670/555 (425~1840)
Rated Annual Power ConsumptionkWh967.40
Rated ISEERWh/Wh4.00
Voltage Range (Stabilizer Inside)V160~265
Operating CurrentA7.64

Indoor unit (IDU)

Panel Colour White
IDU Dimension (HxWxD)mm298x885x229
Package Dimension (HxWxD)375x980x325
IDU Net Weight (Gross Weight)kg11.5 (14.5)
Airflow RateFeet3/min (cfm)572
m3/min (cmm)16.2
Moisture Removall/hr (Litres/Hour)1.6
Operation Sound H/MH/M/ML/L/SLdBA46/43/41/38/35/33

Outdoor unit (ODU)

ODU Dimension (HxWxD)mm595x845x300
Package Dimension (HxWxD)680x1035x410
ODU Net Weight (Gross Weight)kg30 (37)
Compressor Type Variable Speed Rotary Compressor
Refrigerant R-32
Breaker SizeA20
Piping LengthCharge-Lessm10
Max. Length20
Max. Height10
Piping ConnectionGas / Liquidmm (Inch)Φ12.7/φ6.4(1/2”/1/4”)
Operating Ambient Temperature RangeCooling (Min~Max)°C DB20~50
Measurement conditions:
cooling

Cooling capacity is based on: indoor temp. 27°C DB, 19°C WB; outdoor temp. 35°C DB, piping length 5 m.

sound

Sound levels are based on temperature conditions 1. above with 5m piping length. These are anechoic conversion values. These values are normally somewhat higher during actual operation as a result of ambient conditions.

Cooling and heating capacities above are rounded off to first decimal. 1TR (Ton of Refrigeration) = ~3.517 kilowatt.

*Star Rating mentioned above is as per norms defined by Bureau of Energy Efficiency, Ministry of Power, Government of India.

”Value given in Inch. #As per Continuing Policy of Product Innovation at Daikin, The Design, Technical Specifications, Features, Look may change without prior notice

AS A PART OF CONTINOUS DEVELOPMENT AND UPGRADATION THE PRODUCT IMAGE/ACCESSORY/FEATURE/SPECIFICATION MAY BE DIFFERENT FROM ACTUAL PRODUCT AT THE TIME OF PURCHASE.
