GTKM50U

5 Star Premium Series

  • Technology :

    Inverter

  • Star Rating :

  • Capacity kW

    5.28

  • Compressor Warranty :

    10 Yrs

  • PCB Warranty :

    5 Yrs

Melting heat getting the best of you? Not with Daikin’s GTKM series. This technology provides you with a cool and soothing experience even when the temperature hits the 54° Celsius bar. So, you stay comfortable, always.

Salient Features

10 Years Warranty on Compressor

Enjoy long term assurance with 10 Years of peaceful cooling at your house. Daikin provides you tension-free comfort for a decade with a warranty on your air conditioning system's compressor.

5 Years Warranty On PCB

Want additional peace of mind? With Daikin's 5 year warranty on PCB, make your experience more peaceful alongside extra assurance on the maintenance cost and enjoy smooth cooling of your AC in your home.

Air Throw 16* Meters (52 Feet)

With the Cross Flow Evaporator Fans, Daikin air conditioners' every product is perfected and re-perfected to ensure they deliver and carry the badge of trust. Air flow upto 16* metres (52 feet) away from the unit ensures uniform and powerful cooling.

Air throw given for 5.28KW (1.5 TR) capacity, may vary model to model

Specification

Model name Indoor unit (IDU) GTKM50UV16U
Outdoor unit (ODU) RKMG50UV16U
Star Rating*   5 Star
Rated Power Supply Phase/Frequency/Voltage 1φ/50Hz/230V
Power Supply Intake   Outdoor unit
Rated Cooling Capacity Full/Half (min. - max.) kW 5.28/2.64 (1.58~5.75)
Btu/h 18000/9000 (5390~19620)
Cooling capacity @ 46°C % 100%
Rated Power Consumption Full/Half (min. - max.) W 1325/460 (267~1639)
Rated Annual Power Consumption kWh 785.67
Rated ISEER Wh/Wh 5.2
Voltage Range (Stabilizer Inside) V 130~285
Operating Current A 6.1

Indoor unit (IDU)

Panel Colour   White
IDU Dimension (HxWxD) mm 298x885x229
Package Dimension (HxWxD) 375x980x325
IDU Net Weight (Gross Weight) kg 11 (14)
Airflow Rate Feet3/min (cfm) 593
m3/min (cmm) 16.8
Moisture Removal l/hr (Litres/Hour) 1.8
Operation Sound H/MH/M/ML/L/SL dBA 48/46/43/41/38/32

Outdoor unit (ODU)

ODU Dimension (HxWxD) mm 595x845x300
Package Dimension (HxWxD) 680x1035x410
ODU Net Weight (Gross Weight) kg 32.5 (37.5)
Compressor Type   Swing Compressor
Refrigerant   R-32
Breaker Size A 20
Piping Length Charge-Less m 10
Max. Length 20
Max. Height 16
Piping Connection Gas / Liquid mm (Inch) φ12.7/φ6.4 (1/2"/1/4")
Operating Ambient Temperature Range Cooling (Min~Max) °C DB 20~54
Measurement conditions:
cooling

Cooling capacity is based on: indoor temp. 27°C DB, 19°C WB; outdoor temp. 35°C DB, piping length 5 m.

sound

Sound levels are based on temperature conditions 1. above with 5m piping length. These are anechoic conversion values. These values are normally somewhat higher during actual operation as a result of ambient conditions.

Cooling and heating capacities above are rounded off to first decimal. 1TR (Ton of Refrigeration) = ~3.517 kilowatt.

*Star Rating mentioned above is as per norms defined by Bureau of Energy Efficiency, Ministry of Power, Government of India.
" Value given in Inch. #As per Continuing Policy of Product Innovation at Daikin, The Design, Technical Specifications, Features, Look may change without prior notice

AS A PART OF CONTINOUS DEVELOPMENT AND UPGRADATION THE PRODUCT IMAGE/ACCESSORY/FEATURE/SPECIFICATION MAY BE DIFFERENT FROM ACTUAL PRODUCT AT THE TIME OF PURCHASE.
