  • atkm-50

ATKM50U

5 Star Premium Series

  • Technology :

    Inverter

  • Star Rating :

  • Capacity kW

    5.28

  • Compressor Warranty :

    10 Yrs

  • PCB Warranty :

    5 Yrs

Choose the ATKM50 & get the best air conditioning experience at your home. With features like Patented DNNS Self-heal coating & Hepta Sense technology, enjoy peace of mind. Take Care of your World with Daikin - #TheAirSpecialist.

Salient Features

10 Years Warranty on Compressor

Enjoy long term assurance with 10 Years of peaceful cooling at your house. Daikin provides you tension-free comfort for a decade with a warranty on your air conditioning system's compressor.

5 Years Warranty On PCB

Want additional peace of mind? With Daikin's 5 year warranty on PCB, make your experience more peaceful alongside extra assurance on the maintenance cost and enjoy smooth cooling of your AC in your home.

Coanda Airflow

Make way for effective air circulation and efficient temperature distribution with Daikin’s Coanda airflow, designed to give the best air-conditioning experience. This function ensures cooling even in corners of the room by streaming cool air upwards along the ceiling, avoiding furniture or obstructions.

DNNS Self Heal

Every Daikin Room AC’s Indoor Unit (U-bend side) is coated with advanced anti-corrosive coating active agent DNNS (Di-Nonyl Nephthalene Sulfonic Acid). The coating has Self Healing properties that activates upon chipping, scratches due to environmental or chemical pollution.

Hepta Sense

Daikin Swing Inverter ACs has 7 Sensors located on IDU and ODU. Each of these sensors has role to play in the working of Air conditioner that improves overall performance, provide comfort to users and help to increase durability and life of the AC.

Patented Swing Compressor

Daikin Air conditioners come with a Patented Swing Compressor which decreases friction and vibration. This helps in a smooth rotation of the swing compressor which provides a quiet and efficient operation.

Power-Airflow Dual Flaps

The Power-Airflow Dual Flaps along with the Crossflow Evaporator fans ensure even distribution of cool air in both small and large spaces, making sure you are comfortable at all times.

Stabilizer Inside

No need to worry about voltage fluctuation. Daikin's Stabilizer Inside operation regulates voltage across a wide range of fluctuation (130V~285V) and helps ensuring smooth operations during voltage fluctuations.

Specification

Model name Indoor unit (IDU)  ATKM50UV16VA
Outdoor unit (ODU) RKM50UV16VA
Star Rating*   5 Star
Rated Power supply Phase /Frequency/Voltage 1φ/50Hz/230V
Power Supply Intake   Outdoor unit
Rated Cooling Capacity Full/Half (min.~max.) kW 5.28/2.64 (1.58~5.75)
Btu/h 18000/9000 (5390~19620)
Cooling capacity @ 46°C % 100%
Rated Power Consumption Full/Half (min.~max.) W 1360/450 (267~1639)
Rated Annual Power Consumption kWh 785.99
Rated ISEER Wh/Wh 5.2
Voltage Range (Stabilizer Inside) V 130~285
Operating Current A 6.22

Indoor unit (IDU)

Panel Colour   White
IDU Dimension (HxWxD) mm 298x906x235
Package Dimension (HxWxD) 375x1000×330
IDU Net Weight (Gross Weight) kg 10.5 (13.5)
Airflow Rate Feet3/min (cfm) 593
m3/min (cmm) 16.8
Moisture Removal I/hr (Litres/Hour) 1.8
Operation Sound H/MH/M/ML/L/SL dBA 48/46/43/41/38/32

Outdoor unit (ODU)

ODU Dimension (HxWxD) mm 595x845x300
Package Dimension (HxWxD) 680x1035x410
ODU Net Weight (Gross Weight) kg 32.5 (39.5)
Compressor Type   Swing Compressor
Refrigerant   R-32
Breaker size A 20
Piping length Charge-Less m 10
Max Length 20
Max. Height 16
Piping Connection Gas / Liquid mm (Inch) Φ12.7/φ6.4 (1/2"/1/4")
Operating Ambient Temperature Range Cooling (Min-Max) °C DB 20~54
Measurement conditions:
cooling

1. Cooling capacity is based on: indoor temp. 27°C DB, 19°C WB: outdoor temp. 35°C DB, piping length 5 m.

sound

2. Sound levels are based on temperature conditions 1. Above with 5m piping length. These are anechoic conversion values. These values are normally somewhat higher during actual operation as a result of ambient conditions.

Cooling and heating capacities above are rounded off to first decimal. 1TR (Ton of Refrigeration) = ~3.517 kilowatt.

*Star Rating mentioned above is as per norms defined by Bureau of Energy Efficiency, Ministry of Power, Government of India.

‘’Value given in Inch.

As per Continuing Policy of Product Innovation at Daikin, The Design, Technical Specifications, Features, Look may change without prior notice.

AS A PART OF CONTINOUS DEVELOPMENT AND UPGRADATION THE PRODUCT IMAGE/ACCESSORY/FEATURE/SPECIFICATION MAY BE DIFFERENT FROM ACTUAL PRODUCT AT THE TIME OF PURCHASE.
